HC276 gate valve DN50 PN160

HC276 gate valve DN50 PN160

Type
HC276 gate valve DN50 PN160
Size
DN50
Pressure
PN160
Body material
HC276
Trim material
HC276
Connection ends
RF ends

Product Description

Brand:ZYI

Place of Origin:China

Service:OEM&ODM

Packing:inside: Plastic Film, outside: Plywood case

API Standards:
1 Design and manufacture: API 602
2 Face to Face dimension: ASME B16.10
3 Flanged End: ASTM B16.5   RF
4 Pressure test: API 598

Materials of main parts

No

Part

Matarial

1

Body

HC276

2

Seat ring

HC276

3

Wedge

HC276

4

Stem

HC276

5

Gasket

304+Graphite

6

Bonnet

HC276

7

Stud

ASTM A193 B8M

8

Packing Graphite

9

Bushing

C.S

10

Gland

HC276

11

Pin

HC276

12

Gland bolt

ASTM A193 B8M

13

Gland nut

ASTM A194 8M

14

Stem Nut

ASTM A194 8M

15

Gasket

C.S

16

Handwheel

ASTM A197

17

H.W.Lock nut C.S
