ASTM A182 F304 Extended Stem gate valve 1 1/2'' 150LB

ASTM A182 F304 Extended Stem gate valve 1 1/2'' 150LB

Type
ASTM A182 F304 Extended Stem gate valve 1 1/2'' 150LB
Size
1 1/2''
Pressure
150LB
Body material
ASTM A182 F304
Trim material
ASTM A182 F304
Connection ends
RF ends

Product Description

Brand:ZYI

Place of Origin:China

Service:OEM&ODM

Packing:inside: Plastic Film, outside: Plywood case

API Standards:
1 Design and manufacture: API 602
2 Face to Face dimension: ASME B16.10
3 Flanged End: ASTM B16.5   RF
4 Pressure test: API 598

Materials of main parts

No

Part

Matarial

1

Body

ASTM A182 F304

2

Seat ring

ASTM A182 F304

3

Wedge

ASTM A182 F304

4

Stem

ASTM A182 F304

5

Gasket

304+Graphite

6

Bonnet

ASTM A182 F304

7

Stud

ASTM A193 B8

8

Packing Graphite

9

Bushing

C.S

10

Gland

ASTM A182 F304

11

Pin

ASTM A182 F304

12

Gland bolt

ASTM A193 B8

13

Gland nut

ASTM A194 8

14

Stem Nut

ASTM A194 8

15

Gasket

C.S

16

Handwheel

ASTM A197

17

H.W.Lock nut C.S
